Cost-effective Quad Small Form-Factor Pluggable (QSFP) transceivers for 40 Gigabit Ethernet applications
Product overview
UPONCOMM offers customers a wide variety of high-density and low-power 40 Gigabit Ethernet connectivity options for data center, high-performance computing networks, enterprise core and distribution layers, and service provider applications.
UPONCOMM Q40GLR4L module supports link lengths of up to 2 kilometers over a standard pair of G.652 Single-Mode Fiber (SMF) with duplex LC connectors. The 40 Gigabit Ethernet signal is carried over four wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device. It is interoperable with 40GBASE-LR4 for distances up to 2 kilometers. The operating temperature range is from +10 to +60°C with an optical link budget of 4 decibels. This 4-decibel link budget offers the ability to support the loss from patch panels in the link in a data center environment.
Speed | 40GBase-IR4 |
Wavelength | 1310nm |
Distance | 2km |
Interface | LC Duplex |
DOM Support | YES |
Media | MMF |
Optical Componets | DFB CWDM/PIN |
TX Power | -10~-2.3dBm |
RX Power | < -13dBm |
Form Factor | QSFP+ |
Protocols | 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba, MSA Compliant |
Temperature Range | 0 to 70℃ (32 to 158℉) |
